Series C.1 Bathroom faucets #C11010001
Bathroom Sink Faucet S #C11010001
Design by Kurt Merki Jr.
Item may differ from picture. Decorations and accessories are not included.
Ceramic cartridge, Height: 6 1/8 ", Spout reach: 3 5/8 ", Spray pattern: Normal spray, Aerator adjustable, recommended operating pressure: 14.5038 - 72.519 psi, Noise class: I, with rotating handle: lever handle
Variants
select| Chrome, Water connection: Flexible connecting hoses, 9/16”-24 UNEF, Flow rate: 1.06 gal/min, with pop-up and drain assembly, WaterSense: Yes, ADA: Yes, cUPC listed: Yes | 4 3/4 "x6 1/8 " | 3.748 lb | C11010001U10 | $ 420.00 * | |
* Actual pricing may vary and is determined by the selling retailer/wholesaler/dealer.
Downloads
Hint:
Remarks: Dimensions shown in downloads shall not be used for cut-out templates. Cut-out templates are available upon request. All drawings contain the necessary measurements which are subject to standard tolerances. They are stated in inch and mm, are drawn on a scale of 1:20 and are non-binding. Exact measurements, in particular for customized installation scenarios, can only be taken from the finished ceramic piece.
Instructions
Planning data
Product documentation
