Series DuraStyle Toilets #216001
Two-Piece toilet #216001
Design by Matteo Thun & Antonio Rodriguez
Item may differ from picture. Decorations and accessories are not included.
Top Downloads
(without tank), syphonic, 12" rough-in, vertical outlet, WaterSense® listed, cUPC® listed*
* Complies with following standards: ASME A112.19.2/CSA B45.1
Color
Variants
select© Color 00, 1.32/0.92 gpf |
14 1/8" x 27 1/2" Inch | 92 lb | 2160010000 | 285.00 $ * |
* Actual pricing may vary and is determined by the selling retailer/wholesaler/dealer.
| Dimension | Weight | Order number | ||
|
Mounting set | 17 3/4" Inch | 1.1 lb | 001417 |
| for One-Piece and Two-Piece toilets, outlet 3/8" - male thread, wall connection 1/2" - female thread, 1/2'', North American version |
Suitable products
Downloads
Hint:
Remarks: Dimensions shown in downloads shall not be used for cut-out templates. Cut-out templates are available upon request. All drawings contain the necessary measurements which are subject to standard tolerances. They are stated in inch and mm, are drawn on a scale of 1:20 and are non-binding. Exact measurements, in particular for customized installation scenarios, can only be taken from the finished ceramic piece.
BIM (building information modeling) files
Instructions
Planning data
Product documentation
