Series ME by Starck Urinals #280930
Urinal #280930
Design by Philippe Starck
Item may differ from picture. Decorations and accessories are not included.
Flushing rim: Rimless, Flush system: Siphonic, Flush system: Siphonic, Inlet supply position: Rear, Hardware included, Outlet: horizontal, Concealed outflow, ADA: Yes, cC/IAPMO®: Yes
Color
Variants
| White High Gloss, Concealed inflow, cUPC listed: No | 11 3/4 "x23 " | 44.533 lb | 2809300092 | $ 450.00 * | |
* Actual pricing may vary and is determined by the selling retailer/wholesaler/dealer.
Spare parts
| Dimension | Weight | Order number | ||
|
P-Trap | Ø 2" | 0.386 lb | 005113 |
| Outlet: horizontal, 0.13 gal-1.06 gal, Ø 2 " | ||||
|
Water inlet mechanism | 4 3/8" | 0.22 lb | 695800 |
| Urinal | ||||
|
Urinal Screen | 8" | 0.198 lb | 005042 |
| Material: Stainless Steel |
Downloads
Hint:
Remarks: Dimensions shown in downloads shall not be used for cut-out templates. Cut-out templates are available upon request. All drawings contain the necessary measurements which are subject to standard tolerances. They are stated in inch and mm, are drawn on a scale of 1:20 and are non-binding. Exact measurements, in particular for customized installation scenarios, can only be taken from the finished ceramic piece.
BIM (building information modeling) files
Instructions
Planning data
Product documentation
