Series D-Code Sinks #034210
Wall Mounted Sink #034210
Design by sieger design
/website/html/default/7120.us-en.html?p=94850
![](https://wgassets.duravit.com/dimg/991022349_web2_prod_normal_2.jpg)
Wall Mounted Sink, 03421000002 White High Gloss, Number of basins: 1 Middle, Number of faucet holes: 1 Middle, cUPC listed: No
![](https://wgassets.duravit.com/dimg/991022349_web2_prod_normal_2.jpg)
![](https://wgassets.duravit.com/dimg/992658538_web2_prod_normal_2.jpg)
![](https://wgassets.duravit.com/dimg/991022349_web2_prod_normal_2.jpg)
![](https://wgassets.duravit.com/dimg/990347058_web2_prod_normal_2.jpg)
![](https://wgassets.duravit.com/dimg/991022349_web2_prod_normal_2.jpg)
Item may differ from picture. Decorations and accessories are not included.
![](https://wgassets.duravit.com/dimg/991022349_web2_prod_normal_2.jpg?derivate=width~1024)
![](https://wgassets.duravit.com/dimg/992658538_web2_prod_normal_2.jpg?derivate=width~1024)
![](https://wgassets.duravit.com/dimg/991022349_web2_prod_normal_2.jpg?derivate=width~1024)
![](https://wgassets.duravit.com/dimg/990347058_web2_prod_normal_2.jpg?derivate=width~1024)
![](https://wgassets.duravit.com/dimg/991022349_web2_prod_normal_2.jpg?derivate=width~1024)
![](https://wgassets.duravit.com/dimg/991022349_web2_prod_normal_2.jpg)
![](https://wgassets.duravit.com/dimg/992658538_web2_prod_normal_2.jpg)
![](https://wgassets.duravit.com/dimg/991022349_web2_prod_normal_2.jpg)
![](https://wgassets.duravit.com/dimg/990347058_web2_prod_normal_2.jpg)
![](https://wgassets.duravit.com/dimg/991022349_web2_prod_normal_2.jpg)
Rectangular, Includes faucet deck: Yes, Overflow: Yes, Underside glazed, Back side glazed: No, 41 3/8 ", ADA: Yes
Space-saving siphon is recommended in conjunction with vanity unit / To attach washbasins from a size of 1000 mm, two attachments with article no. # 6951000000 are required
Variants
selectp White High Gloss, Number of basins: 1 Middle, Number of faucet holes: 1 Middle, cUPC listed: No |
67.241 lb | 03421000002 | $ 800.00 * | |
p White High Gloss, Number of basins: 1 Middle, Number of faucet holes: 1 Middle, cUPC listed: No |
67.241 lb | 03421000002 | $ 800.00 * | |
ppp White High Gloss, Number of basins: 1 Middle, Number of faucet holes: 3 Middle, Soap dispenser position: Left, cUPC listed: No |
67.241 lb | 03421000302 | $ 800.00 * |
* Actual pricing may vary and is determined by the selling retailer/wholesaler/dealer.
Spare parts
Dimension | Weight | Order number | ||
![]() |
P-Trap | 14 1/8" | 0.82 lb | 005076 |
White, Connection dimensions: 1 1/4" | ||||
![]() |
Towel Bar | 39 3/4" | 1.279 lb | 003035 |
![]() |
Sink Drain | Ø 2 1/2" | 0.75 lb | 005052 |
Suitable for washbasin with overflow, Ø 2 1/2 " |
Spare parts
Suitable products
Downloads
File filter
-
CAD drawings 3D
-
Revit RFA
-
Care instructions
-
Installation instructions
-
CAD drawings 2D (DWG)
-
CAD drawings 2D (DXF)
-
CAD drawings 3D
-
CAD drawings 3D (DWG)
-
CAD drawings 3D (DXF)
-
CAD drawings 3D
-
CAD drawings 3D
-
CAD drawings 3D
-
CAD drawings 3D
-
CAD drawings 3D (IGS)
-
CAD drawings 3D (STP)
-
CAD drawings 3D (WRL)
-
Product images (TIFF)
-
Documents (PDF)
- CAD drawings 3D
- Revit RFA
- Care instructions
- Installation instructions
- CAD drawings 2D (DWG)
- CAD drawings 2D (DXF)
- CAD drawings 3D
- CAD drawings 3D (DWG)
- CAD drawings 3D (DXF)
- CAD drawings 3D
- CAD drawings 3D
- CAD drawings 3D
- CAD drawings 3D
- CAD drawings 3D (IGS)
- CAD drawings 3D (STP)
- CAD drawings 3D (WRL)
- Product images (TIFF)
- Documents (PDF)
Hint:
CAD files should not be used for computer-controlled (CNC) cutting of countertops and are for space-planning & room rendering purposes only. If you wish to order a cut-out template, please contact customer service at 888-DURAVIT or info@us.duravit.com
Remarks: Dimensions shown in downloads shall not be used for cut-out templates. Cut-out templates are available upon request. All drawings contain the necessary measurements which are subject to standard tolerances. They are stated in inch and mm, are drawn on a scale of 1:20 and are non-binding. Exact measurements, in particular for customized installation scenarios, can only be taken from the finished ceramic piece.
BIM (building information modeling) files
Instructions
Planning data
Product documentation
